Portable Ultrasonic Diagnostic Devices, color Doppler
Place of Origin:
2d, CFM, PDI, PW, HPRF, etc
8-section TGC adjustment
2mm to 240mm
100 frame cine loop memory
3 in all, 1 for update in future
20000 Unit/Units per Year color Doppler
Packaging & Delivery
Sea-worthy packing/Air-worthy packing for color Doppler
Best digital portable color doppler ultrasound medical equipment/cheap doppler ultrasound machine scanner price
The SUN-906W Full-Digital color Doppler ultrasound diagnostic system is the latest one of its kind developed by our company. This new generation of portable color Doppler diagnostic system features advanced technology, incomparable performance and complete functions. The product adopted the high-precision digital beam former integrating continuous dynamic focusing technique, dynamic multi-frequency aperture,dynamic filtering and dynamic apodization to ensure real and detailed images. The digital imaging techonology, powerful standard PC platform, professional control panel not only meets the increasing demands for clinical diagnosis but also allows system upgrading. The quality ultrasonic images could be widely used in the examination and diagnosis of abdomen, gynecology, obstetrics, urology, vascular, cardiac, organella as well as superficial organs. It also apply to the family planning program as it could examine early pregnancy and contracedptive ring.
Features: Full imaging mode 2d, CFM, PDI, PW, HPRF, etc. Standard two transducer socket with 15' LCD monitor Full function control panel with black-lit and 8 level TGC Tissue Harmonic Imaging iBeamTM spatial compounding imaging reduces random noise and enhances border differentiation without compromising frame rate iZoomTM automatically expands the image to full screen Full patient database solutions: DICOM3.0, AVI/JPG, USB2.0, HDD, PDF report, etc.
Specification: Display 15" LCD monitor Display model B, 2B, B/M, 4B, B/C TGC: 8-section TGC adjustment Scanning depth 240mm Image processing preset, PRF, gain, Dynamic range, gray map, Black/white, Left/right, Up/down Digital technology DRF&DFS Transducer frequency 2.5-10MHz Gray scale 256 Cine-loop 100 frame cine loop memory iTouch One key for optimization iClear One key for clearer Zoom Pan zoom Probe connector 3 in all, 1 for update in future USB ports 4 Power supply 100-240VAC± 10%, 50Hz/60Hz
Standard Configurations: Main unit 15"LCD with high resolution and contrast 64GB hard disk 2GB DDR Ram INTER Core 2Duo L9400CPU 4 USB ports, 1 S-video output port 2 probe connectors for use, one for update Measurement and Calculation software package ( General, OB/GYN. small parts, Urology) 3.5MHz Electronic convex array probe
